Min. Pesenan:1 Piece/Pieces
Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Ukuran cilik sing dipasang ing ruangan ruangan, 10.1 inci TFT LCD Monitor. Konten sing ditampilake ing layar bisa uga katon kanthi jelas ing lingkungan sing apik, bisa digunakake karo kabeh jinis ngisi, mesin vending layanan dhewe, kios lan terminal server liyane.
Yen sampeyan duwe kabutuhan liyane, hubungi kita, kita bakal ngubungi kita, kita bakal ngatur solusi tampilan kristal kristal sing paling cocog miturut kabutuhan.
Fitur ruangan sing dipasang ing ruangan
10.1 "panel tft lcd
1280 * 800 Resolusi
Outdoor digunakake, padhange saka 500nits nganti 1500 sele opsional
Panel sentuhan capacitive, ditutupi karo kaca kaca temper lan dipercaya kanggo bukti vandal
Antarmuka USB HDDI DVI USB
Mishingboard kinerja dhuwur, 7/24 Operasi terus
Ndhukung voltase sudhut 12-24v
Bawang ngarep-tip ing ngarep, becik kanggo dipasangake dipasang
Panel ngarep Ip55 Nyegah bledug anti banyu
Operasi Suhu Suhu: -10 - 50 ° C
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
