Min. Pesenan:1 Piece/Pieces
Model No.: BA104S01-100
BA104S01-100 minangka Produk Modul LCD LCD LCD LCD LCD diluncurake dening Boe Technology Group Co, ltd. (Boe) nggunakake teknologi A-si TFT-LCD. Iki dilengkapi latar mburi WLED, ora ana drive lampu mburi lan ora ana sentuhan. BA104S01-100 Nampilake resolusi 800 (RGB) × 600 (SVGA), aspek aspek 4: 3 (piksel: dhuwur), miturut spesifikasi produk karo Versi No. .1 dirilis dening Boe tanggal 12 Desember 2014. Ukuran area tampilan 211.2 × 158.4 (ukuran visual) MM, ukuran katon 236 × 176 × 176,9 (jembaré dhuwur) × 5.9 (kekandelan) mm, perawatan lumahing jelas, bobot net produk yaiku 288g (TYP.). Latar mburi produk nggunakake sumber cahya sing ana 6-jam (paling dhuwur), urip sumber 50k jam, ora ana drive lampu mburi. BA104S01-100 nganggo antarmuka sinyal signal (1 CH, 6/8-Bit), total saka 20 pin, nganggo sambungan terminal, voltase layar drive 3.3v (TYP.). Tingkat refresh vertikal khas yaiku 60Hz. Makaryakke ing -20 ° C nganti 70 ° C lan toko ing -30 ° C nganti 80 ° C. Model iki disaranake kanggo nggunakake imaging industri lan medis amarga cahya putih, luwih saka 50.000 jam, flip terminal, 6/8 bit skala abu-abu, lan fitur liyane.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ing ngisor iki minangka model ukuran lan paramèter sing padha
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
