Model No.: EV101WXM-N81
EV101WXM-N81 minangka modul LCD 10,1 inci nggunakake teknologi A-si TFT-LCD. Iki dilengkapi latar mburi wled, kalebu drive latar drive LED, ora ana sentuhan. Resolusi tampilan 1280 (RGB) × 800 (Wxga), rasio aspek yaiku 16:10 (jembaré: dhuwur), lan piksel disusun ing garis-garis vertikal. Ukuran area tampilan yaiku 216.96 × 135,6 (Lebar × dhuwur) mm, ukuran visual 219,4 × 138.0 (ukuran eksternal yaiku 233,2 × 152.9 (Kekandelan) MM, Produk Net 50g (TYP.). Ing syarat-syarat backlighting, produk iki nggunakake sumber sisih entri langsung kanthi urip 50k jam, kalebu driver LED. EV101WXM-N81 Manggih antarmuka sinyal signal (1 CH, 8-bit), total 20 pin, nggunakake sambungan terminal, voltase layar drive 3,3v (TYP.). Tingkat refresh vertikal khas yaiku 60Hz. Makaryakke ing -20 ° C nganti 70 ° C lan toko ing -30 ° C nganti 80 ° C. Adhedhasar lampu latar putih, urip luwih saka 50,000 jam.
R-bintang asale saka Shenzhen, China, kita produsen profesional LCD, kita bisa nyedhiyani Modul LCD TFT TFT TFT, kalebu LCD semiLight TFT TFT, kalebu LCD Sorotan semi Penting LCD, Sorotan Sorotan TFTT-LCD Industrial, LCD Industrial lan Bingkai Tampilan, LCD kaping pindho, LCD sisi kaping pindho sing dhuwur lan panel LCD sing dhuwur lan panel lcd liyane. Singkat, mundhak duwe luwih saka 5 taun pengalaman teknologi lampu lampu mburi sing dhuwur, 8 taun saka modul modul TFT gedhe, riset lan pangembangan, kapasitas produksi, 10 taun saka chain pasokan bahan-bahan sing bermutu.
| brand | BOE | Model name | EV101WXM-N81 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800, WXGA, 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96×135.6(H×V)mm | Surface treatment | / |
| Visual size | 233.2×152.9×10.4(H×V×D) mm | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 233.2×152.9×10.4(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Model lan paramèter ukuran sing padha kaya ing ngisor iki
| brand | BOE | Model name | EV101WUM-N20 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1200, WUXGA, 224PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.806×135.504mm(H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 229.45×149.22(H×V)mm |
| Viewing Angle | 80/80/80/80(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 45 pins | ||
| work environment | Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | AT101WSM-N11-58P0 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×600, WSVGA, 117PPI | Pixel configuration | RGB vertical bar |
| Display Area | 222.72×125.28mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 226×128.6(H×V)mm | Contrast Ratio | 500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 235×144.9×5.44mm(H×V×D) |
| Viewing Angle | 80/80/60/70(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) , 60 pins , FPC | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | EV101WXM-N82 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 [WXGA] 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96 × 135.6 mm (H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 228.6 ×149.2×6 mm (H×V×D) |
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 40 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
