Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Min. Pesenan:1 Piece/Pieces
Model No.: TDA150-005V01
TDA150-00-00-005V01 Modul kristal cair 15-inci, fitur khas yaiku lampu latar putih, kalebu driver LED, permukaan matte. Suhu operasi yaiku -20 ~ 70 ° C, lan suhu panyimpenan kasebut -30 ~ 80 ° C. Résolusi tampilan yaiku 1600 (RGB) × 1200 (Uxga), lan piksel disusun ing garis-garis vertikal RGB. Ukuran area tampilan yaiku 304.8 × 228.6 (w × h) mm, lan dimensi eksternal 317.4 (w) × 242 (h) mm.
Iki minangka sumber cahya sing jelas kanthi umur 30k jam 30k, kalebu driver sing dipimpin. TDA150-005V01 nganggo antarmuka sinyal signal (2 CH, 8-bit), total 40 pin, sing disambungake dening terminal, lan voltase drive 3.3v (TYP.).
P: Sapa kita?
A: R-bintang asale saka Shenzhen, China, kita minangka produsen profesional LCD, kita bisa nyedhiyani modul LCD TFT TFT TFT TFT 100 inci, ana luwih saka 100 karyawan, kalebu 20 insinyur sing berpengalaman. Perusahaan kasebut wis ngliwati ISO9001 / iso14001 / CCC / FCC / FCC / FCC / FCC / FCC / FCC / FCC / FCC / Sertifikat R & D liyane, lan dadi mitra ODM / OEM TINGKAN TINGGI TINGGI KELOMERS Kelas. Amerika, Afrika, Timur Tengah, Eropa, Amérika Tengah lan Oceania.wen percaya yen sampeyan bakal entuk luwih akeh, kita bakal dadi pemasok sing dipercaya ing China.
P: Apa sampeyan pabrikan (pabrik)?
A: Ya, kita. Uga layanan OEM / ODM sing kasedhiya ing kene.welcome kanggo nuduhake ide sampeyan karo kita. Iki minangka kesenengan kanggo nyedhiyakake solusi sing paling apik kanggo sampeyan.
P: Kepiye kita bisa njamin kualitas?
A: Tansah pemeriksaan pungkasan sadurunge pengiriman.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Ukuran lan model sing padha kaya ing ngisor iki:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Tags Panas: Boe TDA150-005V01 15 "Tampilan layar moudle, China, pabrik, murah, layar lcd, layar layar lrd, layar layar lrd, nyorot ips Layar remot, 15 4 layar LCD , panel LCD, modul LCD, tampilan padhang sing dhuwur.
