Model No.: LQ150X1LW96
Resolusi tampilan LQ150x1lw96 1024 (RGB) × 768 (XGA), aspek aspek yaiku 4: 3 (jembar: dhuwur), lan piksel sing diatur ing garis-garis vertikal. Ukuran area tampilan lq150x1lw96 yaiku 304,128 × 228.128 × 228.196 (ukuran sing katon 307,5 (h) × 253.5 (h) × 253 (d) mm. Matte rampung, lapisan hard (3h), bobot net 950g (maksimal)
Lampu latar kasebut nganggo sumber cahya sing dipilih, suhu operasi yaiku -20 ~ 70 ° C, lan suhu panyimpenan yaiku -25 ~ 70 ° C, sing cocog kanggo ifik industri lan medis.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
P: Apa sampeyan pabrikan (pabrik)?
A: Ya, kita. Uga layanan OEM / ODM sing kasedhiya ing kene.welcome kanggo nuduhake ide sampeyan karo kita. Iki minangka kesenengan kanggo nyedhiyakake solusi sing paling apik kanggo sampeyan.
P: Apa aku bisa tuku conto kanggo pesenanku?
A: Ya, monggo hubungi kita.
