Min. Pesenan:1 Piece/Pieces
Brand: Risinglcd
Produktivitas: 150KK
Panggonan Asal: Shen zhen
Certificate: CE/ROSH/UL/ISO9001
| Panel Brand | BOE | Panel Model | MT220WPM-N10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Touch Screen | Without |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Input Voltage | 5.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
Panel lcd tipis ultra-tipis, padhange tekan 1000nit, gambar kasebut isih jelas ing sinar matahari langsung, solusi sing cocog kanggo ruangan ruangan, srengenge sing bisa diobrol, padhang sing bisa diwaca, 600-1000nit.
Layar LCD Tampilan 21.5 inci kanthi modul Lampu LED Lampu Lampu LED Lampu sing LED
Backlight Struktur Lampu Lampu : Kabeh struktur aluminium, entheng lan tipis, apik, dissipasi panas sing efektif.
2, lampu latar : manik-manik lampu putih, padhange dhuwur 50k Lifespan, keseragaman padhang sing sampurna.
3, ngumpul jalur cahya : Struktur aluminium + dipimpin lampu, ndandani lampu lampu aluminium kanggo nggampangake konduksi panas.
4, Lampu Artikel : Struktur aluminium + dipimpin lampu, ndandani lampu mburi ing aluminium
Lampu LCD Modul LCD Modul Murah LCD Maca
Modul LCD Ultra Slim 21.5 inci Sambungake kabel lan masang film reflektif 3M kanggo nggawe lampu lampu kasebut nggambarake luwih seragam menyang sel mbukak merek asli. Ketik kamar sing resik 10,000 kelas lan priksa sumber cahya kanggo mesthekake yen lampu lampu sing dipimpin biasane.
Modul LCD Ultra Slim 21.5 inci kanthi flim optik
Modul lcd sing langsing tinggi nyelehake flim optik: piring panyebaran, film penyebaran, film peningkatan gloss, etc kanggo nambah padhange lan keseragaman ing latar mburi.
Langsing LCD Modul kanthi LG / Samsung / Auo / Boe, etc sel mbukak asli
Modul Modul Modul LCD 21.5 inci iki LCD LCD LCD / Samsung / Auo / Boe, etc sel mbukak asli (kelas normal TNI110 ℃)
Modul LCD Ultra Slim 21.5 inci kanthi papan T-con
Modul LCD LCD 21.5 inci Dolanan T-con, LED Driver Papan, Perlengkapan DC12V DC12V.
Modul Tinggi Highness 21.5 inci kanthi tes padhang
Padhang LCD sing paling gedhe 21.5 inci iki, tes sing padhang, tes warna suhu warna, Tester Padhang Top-7.
