33.8 "Boe rv338fbm-n00 industri industri

Min. Pesenan:1 Piece/Pieces

Atribut Produk
Kemasan & Pengiriman
Other information

Atribut Produk

Model No.: RV338FBM-N00

Kemasan & Pengiriman

Unit Adol:

Piece/Pieces

Pambuka Produk

RV338FBM-N00, modul LCD 33,8 inci kanthi teknologi A-Si TFT-LCD. Fitur khas modul iki: padhang sing dhuwur, lampu lampu putih, kanthi driver LED, layar ultra-wide. Suhu modul modul IS -20 ~ 70 ° C, suhu panyimpenan wis -30 ~ 80 ° C, lan resistensi geter yaiku 1.5G (14,7 m / s²). Akeh panggunaan, cocog kanggo industri, digital signage, panyorot ruangan.

Résolusi Tampilan RV338FBM-N00 2560 (RGB) × 720, rasio aspek yaiku> 3: 1 (jembar: dhuwur), lan piksel sing diatur ing garis-garis vertikal. Ukuran area tampilan yaiku 825.6 × 232.2 (W × H) mm, ukuran sing katon 829.6 × 2663.6 (H) × 267.6 (d) mm. Bobot net 4.40 ± 0.5kgs.

[Dhukungan Lanskap lan Tampilan Vertikal]

Boten kados panel aplikasi TV normal, gambar bisa diwenehake kanthi sampurna ing mode tampilan lanskap utawa vertikal.

Bisa digunakake kanthi apik ing macem-macem lingkungan industri lan komersial kayata eceran, transportasi massa, pemantauan keamanan, lan pusat kontrol keamanan, lan pusat kontrol visual kanggo nyukupi kabutuhan pelanggan.

lcd screen panel

P: Kepiye carane bisa nemokake produk sing cocog?

A: Kirimake syarat sampeyan, kita bakal nyaranake produk standar kita, yen ora cocog, kita bakal nindakake pangaturan & kustomisasi sing dibutuhake.

P: Suwene jaminan?

A: Kajaba karusakan sing disebabake dening faktor manungsa, garansi setaun wiwit tanggal pangiriman. Kahanan khusus bakal dikabari.

high brightness LCD

brand	BOE	Model name	RV338FBM-N00
size	33.8 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	2560(RGB)×720, 78PPI	Pixel configuration	RGB vertical bar
Display Area	825.6×232.2mm	Surface treatment	/
Visual size	829.6×236.2mm(H×V)	Contrast Ratio	1200:1 (Typ.) (TM)
Brightness(cd/m²)	700cd/m²(Typ.)or customized	Outline dimension	863.6×267.6×27.6mm(H×V×D)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Backlight type	WLED, 40K hours, no drive
Signal interface	LVDS (2 ch, 8-bit) , 51 pins ,erminal
work environment	Storage temperature: -20 to 70 °C Operation Temperature: -30 to 80 °C
