Min. Pesenan:1 Piece/Pieces
Model No.: MG4700S01-1
Brand: Risinglcd
Produktivitas: 220k
Panggonan Asal: China
Certificate: CD/ROSH/ISO9001
MG4700S01-1 duwe resolusi tampilan 3840 (RGB) × 180, aspek aspek> 3: 1 (jembar: dhuwur), lan piksel sing diatur ing garis-garis vertikal. Ukuran area tampilan yaiku 1192,3 × 55.89 (W × H) mm, lan ukuran eksternal yaiku 1208.12 × 72.59 (W × H) mm) mm. Suhu operasi MG4700S01-1 yaiku 0 ~ 50 ° C, lan suhu panyimpenan di -20 ~ 60 ° C.
[Layanan siji-mandeg, operasi global lan dhukungan lokal]
Rising Star nyedhiyakake pelanggan sing mandheg, lan produk wis ngliwati tes sing ketat kanggo mesthekake yen kualitas kasebut cocog karo kualitas kasebut; Lan netepake sistem manajemen kualitas sing berpinggung miturut standar kualitas internasional. Operasi Worldwide, kanggo menehi konsultasi teknis sing sampurna, dhukungan lan layanan bisnis.
| brand | CSOT | Model name | MG4700S01-1 |
| size | 47inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×180 81PPI | Pixel configuration | RGB vertical bar |
| Display Area | 1192.3×55.89(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 3000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1208.12×72.59 (H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | V-by-One 8 lane,51 pins,erminal | ||
| supply voltage | 12.0V (Typ.) |
