Model No.: MNF601EA1-1
Suhu operasi mnf601ea1-1 yaiku 0 ~ 50 ° C, lan suhu panyimpenan -20 ~ 60 ° C. Résolusi tampilan MNF601ea1-1 yaiku 3840 (RGB) × 2160 (UHD), aspek aspek yaiku 16: 9 (piksel: dhuwur), lan piksel sing diatur ing garis rempah rgb. Ukuran area MNF601ea1-1 yaiku 345,6 × 194.4 (ukuran ambane) mm, ukuran katon 350.72 (jembar) × 2,6 (ketebalan) mm.
Standardisasi lan kustomisasi kanggo ketemu macem-macem kabutuhan lingkungan.
Panel Tampilan Umum-Tujuan Rising-Star Feature Resolusi Paling Dhuwur, Visibilitas Langsing, lan Urip Product. Aplikasi Produk Cover Mesin Telpon otomatis (ATM), Mesin Terminal (Pos), Kiosk), Komputer Industri, Peralatan Komersial, Peralatan Pabrik, Enteromasi Laut Nampilake ngenteni.
| brand | CSOT | Model name | MNF601EA1-1(CSO1500) |
| size | 15.6inch | Screen type | LTPS TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×2160, UHD | Pixel configuration | RGB vertical bar |
| Display Area | 345.6×194.4(H×V)mm | Surface treatment | mirror(Haze 0%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 350.72×216.07×2.6(H*V*D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | eDP (4 Lanes),eDP1.4,HBR2 (5.4G/lane),40 pins,erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
