48 "700nits modul LTI480hnis1 LCD

Min. Pesenan:1 Piece/Pieces

Atribut Produk
Kemasan & Pengiriman
Other information

Atribut Produk

Model No.: LTI480HN01

Kemasan & Pengiriman

Unit Adol:

Piece/Pieces

Pambuka Produk

Resolusi tampilan LTI480HN01 yaiku 1920 (RGB) × 1080 (FHD), rasio aspek yaiku 16: 9 (jembaré: dhuwur), lan piksel sing diatur ing garis-garis vertikal. Ukuran area tampilan saka tampilan iki yaiku 1054.08 × 592.92 (ukuran w × 560.08 × 598.92 (ukuran katon yaiku 1079.72 (H) × 22.4 (D ) mm, perawatan permukaan yaiku matte (haze 25%), lapisan hard (2h)

Suhu Modul modul iki yaiku 0 ~ 50 ° C, lan suhu panyimpenan -20 ~ 65 ° C. Model iki cocog kanggo digunakake ing digital.

hight brightness lcd moudle

P: Apa ana ukuran utawa spesifikasi liyane sing bisa dipilih?

A: Yen sampeyan butuh macem-macem ukuran utawa spesifikasi, kita bakal nyedhiyakake skema sing paling cocog miturut syarat sampeyan.

P: Suwene jaminan?

A: Kajaba karusakan sing disebabake dening faktor manungsa, garansi setaun wiwit tanggal pangiriman. Kahanan khusus bakal dikabari.

P: Suwene jaminan?

A: Kajaba karusakan sing disebabake dening faktor manungsa, garansi setaun wiwit tanggal pangiriman. Kahanan khusus bakal dikabari.

high brightness LCD

brand	SAMSUNG	Model name	LTI480HN01
size	46 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1080	Pixel configuration	RGB vertical bar
Display Area	1054.08×592.92(H×V)mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (2H)
Visual size	1060.08×598.92(H×V)mm	Contrast Ratio	4000:1 (Typ.) (TM)
Brightness(cd/m²)	700cd/m²(Typ.)or customized	Outline dimension	1079.88×618.72×22.4(H×V×D)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 65 °C Operation Temperature: 0 to 50 °C
Signal interface	LVDS (2 ch, 8-bit) ,erminal,51pins
supply voltage	12.0V (Typ.)

Tags Panas: 46 "700nit LTI480Hn01 datasheet, China, pabrik, murah, kutipan, layar layar LCD, layar layar LCD, layar layar LCD, layar 25 inci , Panel lcd, modul LCD, tampilan padhang sing dhuwur.
